Easylift Wheelchair Platform Lift by LiftUP
VAT Excluded
✅ Easy plug-and-play installation
✅ No costly building preparation
✅ Installation with or without a pit
✅ Indoor or outdoor installation
✅ Adaptive design with more than 1000 different configurations
✅ Integrated electronics
Description
The EASYLIFT Wheelchair Platform Lift by LIFTUP is designed to provide accessibility solutions for individuals using wheelchairs. Known for its innovative design and robust construction, it enhances mobility and independence for users in both residential and commercial settings.
EasyLift is a stylish and durable lifting platform for wheelchair users and those with mobility challenges, providing smooth access up to 1.25 meters. Perfect for both indoor and outdoor use, it ensures quick and comfortable accessibility.
Key Features:
- Compact Design: The EASYLIFT is designed to be space-efficient, making it ideal for areas with limited space.
- Smooth Operation: Equipped with advanced hydraulic or electric mechanisms, ensuring a smooth and quiet lift experience.
- Safety Mechanisms: Includes safety features such as non-slip platforms, safety rails, emergency stop buttons, and backup power options.
- Ease of Use: Simple controls make it user-friendly for individuals with varying levels of mobility.
- Durability: Built with high-quality materials to withstand frequent use and harsh environmental conditions.
- Customization: Available in various sizes and configurations to fit different needs and architectural requirements.
Applications:
- Residential Use: Provides accessibility solutions for homes, enabling wheelchair users to move between floors easily.
- Commercial Use: Ideal for public buildings, offices, and retail spaces to ensure compliance with accessibility standards.
- Public Transport: Used in buses, trains, and other public transport systems to facilitate easy boarding for wheelchair users.
A Wide Range of Possibilities
- You can choose any RAL color to match your preference. The standard color is Grey Gris 900 Sable.
- For a seamless look, you can install your own floorboards on the platform. The standard flooring is non-skid linoleum.
- Customize the lift’s appearance by selecting the design for the door and side panels. Standard models 800/900 come with smoke or clear
- polycarbonate, while model 1100 features safety glass.
- Choose a pit or an external ramp for easy access to the platform.
- One- or two-way external call stations can be wired or wireless and mounted on the wall or a free-standing column.
- The lift has an onboard alarm system to call for help in an emergency.
- You can configure the lift with one or two doors, a safety barrier, and/or an automatic folding ramp for maximum protection when rolling on or off.
- New reversible doors let you choose left- or right-hand side opening on-site.
- Place the onboard operating panel on the right, left, or both sides for easy access.
- An on/off key lock option is available to prevent accidents, especially in public places.
Key Benefits:
- Increased Independence: Allows wheelchair users to navigate different levels without assistance.
- Enhanced Accessibility: Ensures that buildings and transport systems are accessible to all individuals, promoting inclusivity.
- Compliance: Helps buildings and transport systems meet legal accessibility requirements.
Installation and Maintenance:
- Professional Installation: Should be installed by certified professionals to ensure safety and optimal performance.
- Regular Maintenance: Requires routine checks and maintenance to ensure longevity and reliability. LIFTUP provides maintenance services and support.
Nordic Style and Quality
EasyLift embodies Nordic design traditions, focusing on minimalism, functionality, and a natural color palette. It can be customized to suit different settings, integrating seamlessly into various environments. With EasyLift, you have a wide range of options to personalize the lift’s appearance, including color selection, floorboard matching, door and side panel design, and access configurations.
EasyLift 800 Specifications
| Attribute | Value |
|---|---|
| Version | V3 PLUS |
| Lifting capacity | 400 kg |
| Lifting height | 70-1350 mm |
| Lifting speed | 40 mm/s |
| Weight | Approx. 200 kg |
| Length (incl. ramp) | 1808 mm |
| Inside width | 800 mm |
| Overall width | 945 mm |
| Min. Inst. Width | 1060 mm |
| Pit depth | 70 mm |
| Pit length | 1520 mm |
| Battery backup | 30 cycles at 25°C |
| Noise | < 70 dB |
| Duty cycle | 2 min. operation/5 min |
EasyLift 900 Specifications
| Attribute | Value |
|---|---|
| Version | V3 PLUS |
| Lifting capacity | 400 kg |
| Lifting height | 70-1350 mm |
| Lifting speed | 40 mm/s |
| Weight | Approx. 200 kg |
| Length (incl. ramp) | 1808 mm |
| Inside width | 900 mm |
| Overall width | 1045 mm |
| Min. Inst. Width | 1160 mm |
| Pit depth | 70 mm |
| Pit length | 1520 mm |
| Battery backup | 30 cycles at 25°C |
| Noise | < 70 dB |
| Duty cycle | 2 min. operation/5 min |
EasyLift 1100 Specifications
| Attribute | Value |
|---|---|
| Version | V3 PLUS |
| Lifting capacity | 400 kg |
| Lifting height | 70-1350 mm |
| Lifting speed | 40 mm/s |
| Weight | Approx. 250 kg |
| Length (incl. ramp) | 1808 mm |
| Inside width | 1100 mm |
| Overall width | 1260 mm |
| Min. Inst. Width | 1360 mm |
| Pit depth | 70 mm |
| Pit length | 1535 mm |
| Battery backup | 30 cycles at 25°C |
| Noise | < 70 dB |
| Duty cycle | 2 min. operation/5 min |
Conclusion:
The EASYLIFT Wheelchair Platform Lift by LIFTUP is a practical and reliable solution for enhancing accessibility in various settings. Its blend of advanced technology, safety features, and user-friendly design makes it a preferred choice for individuals and organizations aiming to improve mobility and independence for wheelchair users.
For more information or to request a quote, or contact their customer service
Additional information
| Size | 800, 900, 1100 |
|---|
